High-speed automatic edge bander MFZ504A for sale

  • High-speed automatic edge bander  MFZ504A for saleProduct Description Panel thickness
  • Hotline: 86-532-67703247
  • Fax: 86-532-68067870
  • Email:mike@sinosteeler.com
  • Detail

  • Contact Us

High-speed automatic edge bander  MFZ504A for sale

Product Description



Panel thickness

10-40mm

Belt thickness

0.4-3mm (PVC)

Belt width

12-45mm

Min.width of panel

>=50mm

Min.length of panel

>=140mm

Panel feeding speed

<=13m/min

Pneumatic power

0.7Mpa

Power

380V 3N/PE  50HZ

Panel feeding motor

1.5kw

Glue axis motor

0.37kw

End cutting motor

0.55kwx2  18000r/min

Fine trimming motor

0.75kwx2  18000r/min

Buffing motor

0.18kwx2  1400r/min

Heating power of glue tank

1.5kw

Installed power

7.0kw

Glue temperature for edging(reference)

150-180°C

Overall dimensions

2900x750x1360mm

Packaging dimensions

3000x810x1480mm

Net Weight

1080kg

Gross Weight

1280kg

The function:

1..Edging 2.Edge cutting 3.End trimming 4.Fine trimming 5.Scraping 6.Buffing


Packaging & Shipping

1.Packing Details:Stretch film with wooden case or as your request .

2.Shipping: We have rich experience in exporting machines to the world and can supply all kinds of different shipping terms!

3.Timely delivery and transportation!6.jpg2.jpg1.jpg

customer with us


Our Services

1.Good after-sale Services is our strength

1) The machine guarantee is 12 months.

2) 24 hours technical support by email or calling.

3) Friendly English version manual and operation video CD disc.

4)Our engineers can provide services to overseas.

 2.Main Market

Which have been exported to a lot of country and Regions . Such as Europe , Russia, Southeast Asia . Middle East . North America

and south America , Australia .



3.Sample Service :

If you want to test the performance of machine ,we can sent sample to you with cost offer .



4.Customized Service :

Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.



5.We have years of manufacturing woodworking machine,OEM and ODM service available.

FAQ

1) Q: What's the MOQ?

      A: MOQ is one set.

2) Q: Provide custom machine Yes or No?

     A: Yes. We can provide custom machine for clients.

3)  Q: What's the payment terms?

     A: T/T 30% in advance and balance before shipment or by negotiation.

4)  Q: Are you factory or trade company?

     A: We are factory and trade company. STEELER is our brand.

5) Q: How long is the warranty period?

     A: One year warranty period except the quick-wear parts.

6) Q: Do you have professional engineers?

     A: Yes. We have professional engineers and designers. We can provide OEM products.
